CYRF7936-40LFXC
RoHS
RoHS compliant
RoHS compliantPackage 40-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
Tray 1 CyFi? Surface Mount IC RF TxRx + MCU 6mm -97dBm 3.6V 4dBm
PDF
/
Buying Options
Total Price: USD $2.94
Unit Price: USD $2.9374
≥1 USD $2.9374
≥10 USD $2.41015
≥100 USD $2.3351
≥500 USD $2.2591
≥1000 USD $2.18405
Inventory: 16196
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 40-VFQFN Exposed Pad
Number of Pins 40
Technical
Operating Temperature 0°C~70°C
Packaging Tray
Published 2004
Series CyFi?
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 40
Termination SMD/SMT
Type TxRx + MCU
Terminal Finish Matte Tin (Sn)
Subcategory Other Telecom ICs
Voltage - Supply 1.8V~3.6V
Terminal Position QUAD
Number of Functions 1
Supply Voltage 2.4V
Terminal Pitch 0.5mm
Frequency 2.4GHz
Pin Count 40
Power Supplies 2.5/3.3V
Max Dual Supply Voltage 3.6V
Power - Output 4dBm
RF Family/Standard General ISM > 1GHZ
Data Rate (Max) 1Mbps
Serial Interfaces SPI
Current - Receiving 18.4mA~21.2mA
Current - Transmitting 20.8mA~34.1mA
Number of Receivers 1
Modulation DSSS, GFSK
Sensitivity (dBm) -97 dBm
GPIO 4
Dimensions
Length 6mm
Width 6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
