MASWSS0143TR-3000
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-6
Category RF/IF and RFID / RF Switches
Description
IC RF SWITCH SPDT 3GHZ SOT26
PDF
/
Buying Options
Total Price: USD $2.38
Unit Price: USD $2.3848
≥1 USD $2.3848
≥10 USD $2.14368
≥100 USD $2.021888
≥500 USD $1.722776
≥1000 USD $1.617616
≥3000 USD $1.41541
Inventory: 1322
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
On Time-Nom 0.02 μs
P1dB 36dBm
RF Type Cellular, CDMA, PCS, TDMA, W-CDMA
Insertion Loss (dB) 0.5 dB
VSWR-Max 1.2
Isolation 11dB
Insertion Loss 0.65dB
RF/Microwave Device Type DIVERSITY SWITCH
Frequency Range DC~3GHz
Turn-Off Delay Time 20 ns
Topology Reflective
Turn On Delay Time 20 ns
Impedance 50Ohm
Operating Supply Current 5μA
Max Supply Voltage 5V
Power Supplies 5V
Circuit SPDT
Frequency 3GHz
Construction COMPONENT
Number of Functions 1
Technology GAAS
Subcategory RF/Microwave Switches
Additional Feature HIGH RELIABILITY
Terminal Finish Matte Tin (Sn)
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2005
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Weight 29.993795mg
Number of Pins 6
Mounting Feature SURFACE MOUNT
Surface Mount YES
Package / Case SOT-23-6
Supply Chain
Factory Lead Time 12 Weeks
