S547AN
RoHS
/
Package Module, SMA Connectors
Category RF/IF and RFID / RF Switches
Description
Module SMA Connectors General Purpose SP5T 35dBm RF Switch IC 2.6dB (Max) 4GHz~12GHz 0C~70C
PDF
/
Inventory: 4578
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
IIP3 35dBm
RF Type General Purpose
VSWR-Max 1.8
Operating Frequency-Min 4000MHz
Isolation 55dB (min)
Insertion Loss 2.6dB (Max)
Operating Frequency-Max 12000MHz
Frequency Range 4GHz~12GHz
Topology Reflective
Test Frequency 12GHz
Circuit SP5T
Part Status Active
Operating Temperature 0°C~70°C
Physical
Package / Case Module, SMA Connectors
