UPG2409T6X-E2-A
RoHS
/
Package 6-XFDFN Exposed Pad
Category RF/IF and RFID / RF Switches
Description
RF Switch ICs .05-6GHz SPDT 3.0Volts
PDF
/
Buying Options
Total Price: USD $0.66
Unit Price: USD $0.66
≥1 USD $0.66
Inventory: 102192
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
IIP3 60dBm
P1dB 36dBm
RF Type 802.11a/b/g/n
Insertion Loss (dB) 0.35 dB
Isolation 27dB
Insertion Loss 0.65dB
Frequency Range 50MHz~6GHz
Topology Reflective
Nominal Supply Current 100nA
Impedance 50Ohm
Test Frequency 6GHz
Min Supply Voltage 2.7V
Max Supply Voltage 3.3V
Circuit SPDT
Frequency 50MHz
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Tape & Reel (TR)
Operating Temperature -45°C~85°C
Physical
Number of Pins 6
Package / Case 6-XFDFN Exposed Pad
