UPG2183T6C-E2-A

CEL
RoHS
/
Package 16-WFQFN Exposed Pad
Category RF/IF and RFID / RF Switches
Description RF Switch ICs .5-2.5GHz SP4T 3.0Volts
PDF
/
Buying Options
Total Price: USD $2.82
Unit Price: USD $2.81675
≥1 USD $2.81675
≥10 USD $2.31135
≥100 USD $2.23915
≥500 USD $2.16695
≥1000 USD $2.09475
Inventory: 34009
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Technical

RF Type Cellular
Insertion Loss (dB) 0.4 dB
Isolation 17dB
Insertion Loss 0.7dB
Frequency Range 500MHz~2.5GHz
Topology Reflective
Turn On Delay Time 100 μs
Throw Configuration SP4T
Nominal Supply Current 100μA
Impedance 50Ohm
Test Frequency 2.5GHz
Min Supply Voltage 2.9V
Max Supply Voltage 3.2V
Circuit SP4T
Frequency 500MHz
Voltage - Supply 2.9V~3.2V
Min Operating Temperature -45°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Tape & Reel (TR)
Operating Temperature -45°C~85°C

Physical

Supplier Device Package 16-QFN (3x3)
Number of Pins 16
Package / Case 16-WFQFN Exposed Pad
