HMC322LP4E
RoHS
RoHS compliant
RoHS compliantPackage 24-VFQFN Exposed Pad
Category RF/IF and RFID / RF Switches
Description
IC SWITCH SP8T 8GHZ NEG 24-QFN
PDF
/
Buying Options
Total Price: USD $30.14
Unit Price: USD $30.1378
≥1 USD $30.1378
≥10 USD $24.7285
≥100 USD $23.95615
≥500 USD $23.18285
≥1000 USD $22.4105
Inventory: 1639
Minimum: 1
-
+
Technical Details
Technical
Frequency Range DC~8GHz
Insertion Loss 2.5dB
Isolation 25dB
Insertion Loss (dB) 2.5 dB
RF Type General Purpose
Input Power-Max (CW) 26.02dBm
P1dB 23dBm
IIP3 40dBm
On Time-Nom 0.15 μs
1dB Compression Point 23 dBm
Topology Absorptive
Impedance 50Ohm 75Ohm
Min Supply Voltage -5.5V
Max Supply Voltage -4.5V
Circuit SP8T
Operating Supply Voltage -5V
Pin Count 24
Base Part Number HMC322
Frequency 8GHz
Construction COMPONENT
Number of Functions 1
Technology GAAS
Max Power Dissipation 348mW
Subcategory RF/Microwave Switches
HTS Code 8542.39.00.01
Additional Feature HIGH ISOLATION
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e3
Packaging Strip
Operating Temperature -40°C~85°C
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
Physical
Weight 928.191737mg
Number of Pins 24
Package / Case 24-VFQFN Exposed Pad
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status LAST TIME BUY (Last Updated: 2 weeks ago)
