HMC232
RoHS
RoHS compliant
RoHS compliantPackage Die
Category RF/IF and RFID / RF Switches
Description
RF Switch ICs Hi Iso SPDT Swt ChipDC - 15 GHz
PDF
/
Inventory: 1811
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Technical
1dB Compression Point 26 dBm
On Time-Nom 0.005 μs
IIP3 49dBm
P1dB 26dBm
RF Type VSAT
Insertion Loss (dB) 1.4 dB
Isolation 50dB
Insertion Loss 2.2dB
Frequency Range 0Hz~15GHz
Topology Absorptive
Impedance 50Ohm
Test Frequency 10GHz
Power Supplies -5V
Circuit SPDT
Pin Count 0
Base Part Number HMC232
Frequency 15GHz
Construction COMPONENT
Number of Functions 1
Technology GAAS
Subcategory RF/Microwave Switches
Additional Feature HIGH ISOLATION
Terminal Finish Gold (Au)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e4
Packaging Bulk
Operating Temperature -55°C~85°C
Physical
Number of Pins 0
Package / Case Die
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 2 weeks ago)
