JN3-B3A3-LY

Telit
RoHS
/
Package 24-SMD Module
Category RF/IF and RFID / RF Receivers
Description RF RCVR GPS 1575.42MHZ MODULE
PDF
/
Inventory: 9297
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Width 12.2mm
Length 16mm
Height Seated (Max) 2.5mm

Technical

Sensitivity (dBm) -163 dBm
Modulation or Protocol GPS
Current - Receiving 32mA
Data Rate (Max) 9.6kbps
Telecom IC Type TELECOM CIRCUIT
Data Interface Pads for Pins
Memory Size 16MB Flash
JESD-30 Code R-XDMA-N24
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 1575.42MHz
Reach Compliance Code unknown
Terminal Pitch 1.1mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position DUAL
Voltage - Supply 2.85V~3.6V
HTS Code 8542.39.00.01
Applications GPS Receiver
Number of Terminations 24
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Published 2012
Packaging Tray
Operating Temperature -40°C~85°C

Physical

Surface Mount NO
Package / Case 24-SMD Module
