STA8090EXGA
RoHS
/
Package 169-TFBGA
Category RF/IF and RFID / RF Receivers
Description
RX GNSS 4.092MHZ-1.561GHZ 169BGA
PDF
/
Buying Options
Total Price: USD $6.87
Unit Price: USD $6.866467
≥1 USD $6.866467
≥200 USD $2.65731
≥500 USD $2.564094
≥1000 USD $2.518142
Inventory: 2016
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 9mm
Length 9mm
Height Seated (Max) 1.2mm
Technical
Antenna Connector PCB, Surface Mount
Modulation or Protocol BeiDou, Galileo, GLONASS, GNSS, GPS
Data Rate (Max) 12Mbps
Sensitivity -162dBm
Telecom IC Type TELECOM CIRCUIT
Screening Level AEC-Q100
Data Interface I2C, SPI, UART, USB
Memory Size 256kB SRAM 512kB ROM
JESD-30 Code S-PBGA-B169
Base Part Number STA8090
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 4.092MHz~1.561GHz 8.57MHz~1.575GHz 10.23MHz~1.601GHz
Terminal Pitch 0.65mm
Supply Voltage 1.1V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form BALL
Terminal Position BOTTOM
Voltage - Supply 1.08V~1.32V
Technology CMOS
Applications General Purpose
Terminal Finish Matte Tin (Sn)
Number of Terminations 169
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 169-TFBGA
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 19 Weeks
