STA8089FGTR
RoHS
/
Package 56-VFQFN Exposed Pad
Category RF/IF and RFID / RF Receivers
Description
RF RX GNSS 1.561/1.575GHZ 56QFPN
PDF
/
Buying Options
Total Price: USD $14.77
Unit Price: USD $14.7668
≥1 USD $14.7668
≥10 USD $12.1163
≥100 USD $11.7382
≥500 USD $11.35915
≥1000 USD $10.9801
Inventory: 2509
Minimum: 1
-
+
Technical Details
Dimensions
Width 7mm
Length 7mm
Height Seated (Max) 0.9mm
Technical
Antenna Connector PCB, Surface Mount
Modulation or Protocol BeiDou, Galileo, GLONASS, GNSS, GPS
Data Rate (Max) 12Mbps
Sensitivity -162dBm
Telecom IC Type RF AND BASEBAND CIRCUIT
Data Interface I2C, SPI, UART
Memory Size 256kB SRAM 512kB ROM
JESD-30 Code S-XQCC-N56
Base Part Number STA8089
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 1.561GHz 1.575GHz 1.601GHz
Reach Compliance Code compliant
Terminal Pitch 0.4mm
Supply Voltage 1.2V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 1.08V~1.32V
Technology CMOS
HTS Code 8542.39.00.01
Applications General Purpose
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code 7A994
Number of Terminations 56
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 56-VFQFN Exposed Pad
Supply Chain
Factory Lead Time 19 Weeks
