E-TDA7514
RoHS
RoHS compliant
RoHS compliantPackage 80-LQFP
Category RF/IF and RFID / RF Receivers
Description
IC TUNER AM/FM CAR RADIO 80-TQFP
PDF
/
Inventory: 7383
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 14mm
Length 14mm
Height Seated (Max) 1.6mm
Technical
Output Voltage-Nom (AM) 370mV
Demodulation Type AM/FM
Output Voltage-Nom (FM) 243mV
Antenna Connector PCB, Surface Mount
Harmonic Distortion 0.02%
Modulation or Protocol AM, FM
Current - Receiving 80mA
Signal to Noise Ratio (SNR) 65 dB
Consumer IC Type AUDIO SINGLE CHIP RECEIVER
Data Interface PCB, Surface Mount
Pin Count 80
Base Part Number TDA7514
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 250
Terminal Form GULL WING
Terminal Position QUAD
HTS Code 8542.39.00.01
Applications Automotive Audio
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 80
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tray
Physical
Number of Pins 80
Surface Mount YES
Package / Case 80-LQFP
