SI4824-A10-CUR
RoHS
/
Package 24-SSOP (0.154, 3.90mm Width)
Category RF/IF and RFID / RF Receivers
Description
RF RX AM/FM 504KHZ-1.75MHZ SSOP
PDF
/
Buying Options
Total Price: USD $1.36
Unit Price: USD $1.362919
≥1 USD $1.362919
≥10 USD $1.285773
≥100 USD $1.21299
≥500 USD $1.144333
≥1000 USD $1.079561
Inventory: 7246
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 3.9mm
Length 8.65mm
Height Seated (Max) 1.75mm
Technical
Output Voltage-Nom (AM) 54mV
Demodulation Type AM/FM
Output Voltage-Nom (FM) 72mV
Antenna Connector PCB, Surface Mount
Harmonic Distortion 0.1%
Modulation or Protocol AM, FM
Current - Receiving 21mA
Signal to Noise Ratio (SNR) 45 dB
Consumer IC Type AUDIO SINGLE CHIP RECEIVER
Data Interface PCB, Surface Mount
Supply Voltage-Min (Vsup) 2V
Supply Voltage-Max (Vsup) 3.6V
JESD-30 Code R-PDSO-G24
Pin Count 24
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 504kHz~1.75MHz 64MHz~109MHz
Terminal Pitch 0.635mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~3.6V
Technology CMOS
HTS Code 8542.39.00.01
Applications Automotive Audio
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Not For New Designs
Published 1997
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Surface Mount YES
Package / Case 24-SSOP (0.154, 3.90mm Width)
Supply Chain
Factory Lead Time 6 Weeks
