SI4735-D60-GUR
RoHS
/
Package 24-SSOP (0.154, 3.90mm Width)
Category RF/IF and RFID / RF Receivers
Description
RF Receiver BC AM/FM/SW/LW AUXIN RADIO RCVR/RDS/RBDS
PDF
/
Buying Options
Total Price: USD $13.42
Unit Price: USD $13.42445
≥1 USD $13.42445
≥10 USD $11.01525
≥100 USD $10.6704
≥500 USD $10.3265
≥1000 USD $9.9826
Inventory: 201
Minimum: 1
-
+
Technical Details
Technical
Power Supplies 1.8/3.33/5V
Supply Voltage-Min (Vsup) 2.7V
Nominal Supply Current 8.2mA
Operating Supply Voltage 5.5V
Qualification Status Not Qualified
Pin Count 24
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 153kHz~279kHz 520kHz~1.71MHz 2.3MHz~26.1MHz 64MHz~108MHz
Terminal Pitch 0.635mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~5.5V
Technology CMOS
Subcategory Other Consumer ICs
HTS Code 8542.39.00.01
Applications General Purpose
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Feature RSSI Equipped
Published 1997
Packaging Tape & Reel (TR)
Operating Temperature -20°C~85°C
Output Voltage-Nom (AM) 60mV
Demodulation Type AM/FM
Output Voltage-Nom (FM) 80mV
Antenna Connector PCB, Surface Mount
Harmonic Distortion 0.1%
Modulation or Protocol AM, FM, LW-SW, WB
Current - Receiving 18.5mA
Signal to Noise Ratio (SNR) 58 dB
Consumer IC Type AUDIO SINGLE CHIP RECEIVER
Data Interface PCB, Surface Mount
Physical
Number of Pins 24
Surface Mount YES
Package / Case 24-SSOP (0.154, 3.90mm Width)
Supply Chain
Factory Lead Time 8 Weeks
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 3.9mm
Length 8.65mm
Height Seated (Max) 2mm
