SI4735-D60-GM
RoHS
/
Package 20-UFQFN Exposed Pad
Category RF/IF and RFID / RF Receivers
Description
Tray 1 AM FM SW-LW PCB Surface Mount RF Receiver 3mm 60mV 58dB 153kHz~279kHz 520kHz~1.71MHz 2.3MHz~26.1MHz 64MHz~108MHz
PDF
/
Buying Options
Total Price: USD $5.23
Unit Price: USD $5.2272
≥1 USD $5.2272
≥10 USD $4.66576
≥100 USD $4.199712
≥500 USD $3.82624
≥1000 USD $3.453006
≥3000 USD $3.098366
Inventory: 1751
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Package / Case 20-UFQFN Exposed Pad
Surface Mount YES
Number of Pins 20
Technical
Operating Temperature -20°C~85°C
Packaging Tray
Published 1997
Feature RSSI Equipped
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 20
ECCN Code EAR99
Applications General Purpose
HTS Code 8542.39.00.01
Subcategory Other Consumer ICs
Technology CMOS
Voltage - Supply 2.7V~5.5V
Terminal Position QUAD
Number of Functions 1
Terminal Pitch 0.5mm
Depth 3mm
Frequency 153kHz~279kHz 520kHz~1.71MHz 2.3MHz~26.1MHz 64MHz~108MHz
Pin Count 20
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 1.8/3.33/5V
Supply Voltage-Min (Vsup) 2.7V
Data Interface PCB, Surface Mount
Consumer IC Type AUDIO SINGLE CHIP RECEIVER
Signal to Noise Ratio (SNR) 58 dB
Current - Receiving 10.5mA
Modulation or Protocol AM, FM, SW-LW
Harmonic Distortion 0.1%
Antenna Connector PCB, Surface Mount
Output Voltage-Nom (FM) 80mV
Demodulation Type AM/FM
Output Voltage-Nom (AM) 60mV
Dimensions
Height Seated (Max) 0.6mm
Length 3mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
