MICRF022BM-FS48
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category RF/IF and RFID / RF Receivers
Description
Tube 1 ASK OOK PCB Surface Mount RF Receiver 4.9mm -97dBm 5.5V 300MHz~440MHz
PDF
/
Buying Options
Total Price: USD $2.24
Unit Price: USD $2.244
≥1 USD $2.244
Inventory: 1938
Minimum: 1
-
+
Technical Details
Technical
Frequency 300MHz~440MHz
Terminal Pitch 1.27mm
Number of Functions 1
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.5V
Applications RKE
Terminal Finish TIN LEAD
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tube
Operating Temperature -40°C~85°C
Antenna Connector PCB, Surface Mount
Modulation or Protocol ASK, OOK
Current - Receiving 2.2mA
Data Rate (Max) 10kbps
Sensitivity -97dBm
Consumer IC Type CONSUMER CIRCUIT
Data Interface PCB, Surface Mount
Supply Voltage-Min (Vsup) 4.75V
Supply Voltage-Max (Vsup) 5.5V
Qualification Status COMMERCIAL
JESD-30 Code R-PDSO-G8
Pin Count 8
Time@Peak Reflow Temperature-Max (s) 30
Physical
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.879mm
