MICRF022BM-FS12
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category RF/IF and RFID / RF Receivers
Description
Tube 1 ASK OOK PCB Surface Mount RF Receiver 4.9mm -97dBm 5.5V 300MHz~440MHz
PDF
/
Buying Options
Total Price: USD $1.29
Unit Price: USD $1.2936
≥1 USD $1.2936
Inventory: 885
Minimum: 1
-
+
Technical Details
Physical
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tube
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Terminal Finish TIN LEAD
Applications RKE
Voltage - Supply 4.75V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Terminal Pitch 1.27mm
Frequency 300MHz~440MHz
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 8
JESD-30 Code R-PDSO-G8
Qualification Status COMMERCIAL
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.75V
Data Interface PCB, Surface Mount
Consumer IC Type CONSUMER CIRCUIT
Sensitivity -97dBm
Data Rate (Max) 10kbps
Current - Receiving 2.2mA
Modulation or Protocol ASK, OOK
Antenna Connector PCB, Surface Mount
Dimensions
Height Seated (Max) 1.879mm
Length 4.9mm
Width 3.9mm
Compliance
RoHS Status Non-RoHS Compliant
