MC33596FJE
RoHS
RoHS compliant
RoHS compliantPackage 32-LQFP
Category RF/IF and RFID / RF Receivers
Description
- RF Receiver FSK, OOK 304, 315, 426, 434, 868, 915MHz -104dBm 22.4 kBaud PCB, Surface Mount 32-LQFP (5x5)
PDF
/
Buying Options
Total Price: USD $3.94
Unit Price: USD $3.9425
≥1 USD $3.9425
≥10 USD $3.2357
≥100 USD $3.13405
≥500 USD $3.03335
≥1000 USD $2.9317
Inventory: 1167
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5mm
Length 5mm
Height Seated (Max) 1.6mm
Technical
Antenna Connector PCB, Surface Mount
Modulation or Protocol FSK, OOK
Current - Receiving 10.3mA
Data Rate (Max) 22.4kBaud
Sensitivity -104dBm
Telecom IC Type TELECOM CIRCUIT
Data Interface PCB, Surface Mount
JESD-30 Code S-PQFP-G32
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 304 315 426 434 868 915MHz
Terminal Pitch 0.5mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position QUAD
Voltage - Supply 2.7V~3.6V 4.5V~5.5V
HTS Code 8542.39.00.01
Applications General Data Transfer
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Published 2009
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 32-LQFP
