T5761-TGS
RoHS
/
Package 20-SOIC (0.295, 7.50mm Width)
Category RF/IF and RFID / RF Receivers
Description
IC RCVR902-928MHZ ASK/FSK 20SOIC
PDF
/
Inventory: 4340
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case 20-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~105°C
Packaging Tube
Published 1997
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Terminal Finish TIN LEAD
Applications General Purpose Data Transmission Systems
HTS Code 8542.39.00.01
Subcategory Other Telecom ICs
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 1.27mm
Frequency 915MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDSO-G20
Qualification Status Not Qualified
Power Supplies 5V
Data Interface PCB, Surface Mount
Telecom IC Type TELECOM CIRCUIT
Sensitivity -110dBm
Data Rate (Max) 10kBaud
Current - Receiving 7.8mA
Modulation or Protocol ASK, FSK
Antenna Connector PCB, Surface Mount
Dimensions
Height Seated (Max) 2.6mm
Length 12.825mm
Width 7.4mm
Compliance
RoHS Status Non-RoHS Compliant
