MICRF005BM
RoHS
/
Package 14-SOIC (0.154, 3.90mm Width)
Category RF/IF and RFID / RF Receivers
Description
Tube 1 OOK PCB Surface Mount RF Receiver 8.65mm -84dBm 5.5V 800MHz~1GHz
PDF
/
Buying Options
Total Price: USD $1.41
Unit Price: USD $1.408
≥1 USD $1.408
Inventory: 544
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 3.9mm
Length 8.65mm
Height Seated (Max) 1.6mm
Technical
Antenna Connector PCB, Surface Mount
Modulation or Protocol OOK
Current - Receiving 10mA
Data Rate (Max) 115kbps
Sensitivity -84dBm
Consumer IC Type CONSUMER CIRCUIT
Data Interface PCB, Surface Mount
Supply Current-Max 18.5mA
Supply Voltage-Min (Vsup) 4.75V
Supply Voltage-Max (Vsup) 5.5V
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G14
Pin Count 14
Time@Peak Reflow Temperature-Max (s) 30
Frequency 800MHz~1GHz
Reach Compliance Code not_compliant
Terminal Pitch 1.27mm
Number of Functions 1
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.3V
HTS Code 8542.39.00.01
Applications Wireless Game Controllers
Terminal Finish Tin/Lead (Sn85Pb15)
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Automatic Tuning
JESD-609 Code e0
Published 2002
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 14-SOIC (0.154, 3.90mm Width)
