MAX2120CTI+T
RoHS
RoHS compliant
RoHS compliantPackage 28-WFQFN Exposed Pad
Category RF/IF and RFID / RF Receivers
Description
RF RCVR 925MHZ-2.175GHZ 28TQFN
PDF
/
Buying Options
Total Price: USD $4.03
Unit Price: USD $4.028
≥1 USD $4.028
≥10 USD $3.30505
≥100 USD $3.2015
≥500 USD $3.09795
≥1000 USD $2.99535
Inventory: 729
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5mm
Length 5mm
Height Seated (Max) 0.8mm
Technical
Built-in IF Amplifier YES
Antenna Connector PCB, Surface Mount
Noise Figure 9 dB
Current - Receiving 100mA
Consumer IC Type VIDEO TUNER
Data Interface PCB, Surface Mount
Supply Current-Max 160mA
Supply Voltage-Min (Vsup) 3.13V
Power Supplies 3.3V
Supply Voltage-Max (Vsup) 3.47V
Qualification Status Not Qualified
Pin Count 28
Base Part Number MAX2120
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 925MHz~2.175GHz
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 3.13V~3.47V
Technology BICMOS
Subcategory Other Consumer ICs
HTS Code 8542.39.00.01
Applications DVB, DSS
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Number of Pins 28
Surface Mount YES
Package / Case 28-WFQFN Exposed Pad
Supply Chain
Factory Lead Time 9 Weeks
