MAX1471ATJ/V+T
RoHS
RoHS compliant
RoHS compliantPackage 32-WQFN Exposed Pad
Category RF/IF and RFID / RF Receivers
Description
RF Receiver ASK/FSK 3V/5V 32-Pin TQFN EP T/R
PDF
/
Buying Options
Total Price: USD $1.67
Unit Price: USD $1.667383
≥1 USD $1.667383
≥200 USD $0.645947
≥500 USD $0.622315
≥1000 USD $0.611811
Inventory: 3523
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 5mm
Length 5mm
Height Seated (Max) 0.8mm
Technical
Modulation or Protocol ASK, FSK
Current - Receiving 8.5mA
Data Rate (Max) 66kbps
Sensitivity -114dBm
Telecom IC Type TELECOM CIRCUIT
Screening Level AEC-Q100
Data Interface SPI
Base Part Number MAX1471
Frequency 300MHz~450MHz
Terminal Pitch 0.5mm
Supply Voltage 3V
Number of Functions 1
Terminal Position QUAD
Voltage - Supply 2.4V~3.6V 4.5V~5.5V
Technology CMOS
HTS Code 8542.39.00.01
Applications General Purpose
Terminal Finish Matte Tin (Sn)
Number of Terminations 32
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature RSSI Equipped
JESD-609 Code e3
Published 2017
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 32
Surface Mount YES
Package / Case 32-WQFN Exposed Pad
Supply Chain
Factory Lead Time 6 Weeks
