MAX1470EUI+
RoHS
RoHS compliant
RoHS compliantPackage 28-TSSOP (0.173, 4.40mm Width)
Category RF/IF and RFID / RF Receivers
Description
RF RECEIVER ASK 315MHZ 28TSSOP
PDF
/
Buying Options
Total Price: USD $3.48
Unit Price: USD $3.4848
≥1 USD $3.4848
≥10 USD $3.10816
≥100 USD $2.79752
≥500 USD $2.548832
≥1000 USD $2.300214
≥3000 USD $2.189
Inventory: 241
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Thickness 750μm
Width 1.1mm
Length 9.6mm
Technical
Antenna Connector PCB, Surface Mount
Sensitivity (dBm) -115 dBm
Modulation or Protocol ASK
Telecom IC Type TELECOM CIRCUIT
Data Interface PCB, Surface Mount
Data Rate 100 kbps
Nominal Supply Current 5.5mA
Operating Supply Voltage 3.3V
Qualification Status Not Qualified
Pin Count 28
Base Part Number MAX1470
Time@Peak Reflow Temperature-Max (s) 30
Frequency 315MHz
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~3.6V
Technology CMOS
HTS Code 8542.39.00.01
Applications ISM, Garage Door Openers, RKE
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2011
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 28
Surface Mount YES
Package / Case 28-TSSOP (0.173, 4.40mm Width)
Supply Chain
Factory Lead Time 6 Weeks
