TDA5225XUMA1
RoHS
RoHS compliant
RoHS compliantPackage 28-TSSOP (0.173, 4.40mm Width)
Category RF/IF and RFID / RF Receivers
Description
Receiver ASK/FSK 3.3V/5V 28-Pin TSSOP T/R
PDF
/
Buying Options
Total Price: USD $2.41
Unit Price: USD $2.4073
≥1 USD $2.4073
≥10 USD $1.97505
≥100 USD $1.9133
≥500 USD $1.85155
≥1000 USD $1.7898
Inventory: 1099
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 4.4mm
Length 9.7mm
Height Seated (Max) 1.2mm
Technical
Antenna Connector PCB, Surface Mount
Modulation or Protocol ASK, FSK
Current - Receiving 12mA
Sensitivity -119dBm
Telecom IC Type TELECOM CIRCUIT
Data Interface PCB, Surface Mount
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G28
Pin Count 28
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 300MHz~320MHz 425MHz~450MHz 863MHz~870MHz 902MHz~928MHz
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~3.6V 4.5V~5.5V
HTS Code 8542.39.00.01
Applications RKE, TPM, Security Systems
Terminal Finish Nickel/Palladium/Gold/Silver (Ni/Pd/Au/Ag)
Number of Terminations 28
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Feature RSSI Equipped
JESD-609 Code e4
Series SmartLEWIS?
Published 2001
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C
Physical
Surface Mount YES
Package / Case 28-TSSOP (0.173, 4.40mm Width)
Supply Chain
Factory Lead Time 39 Weeks
