TDA5201XUMA1
RoHS
RoHS compliant
RoHS compliantPackage 28-TSSOP (0.173, 4.40mm Width)
Category RF/IF and RFID / RF Receivers
Description
IC LP SGL CONV ASK P-TSSOP-28
PDF
/
Buying Options
Total Price: USD $14.86
Unit Price: USD $14.8561
≥1 USD $14.8561
≥10 USD $12.18945
≥100 USD $11.8085
≥500 USD $11.42755
≥1000 USD $11.0466
Inventory: 1165
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 39 Weeks
Physical
Package / Case 28-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2007
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 28
Terminal Finish Tin (Sn)
Applications Alarm Systems, Communication Systems
HTS Code 8542.39.00.01
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.65mm
Frequency 310MHz~350MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 28
JESD-30 Code R-PDSO-G28
Qualification Status Not Qualified
Data Interface PCB, Surface Mount
Telecom IC Type TELECOM CIRCUIT
Sensitivity -107dBm
Current - Receiving 4.8mA
Modulation or Protocol ASK
Antenna Connector PCB, Surface Mount
Dimensions
Height Seated (Max) 1.2mm
Length 9.7mm
Width 4.4mm
Compliance
RoHS Status ROHS3 Compliant
