PD22-73LF
RoHS
RoHS compliant
RoHS compliantPackage SOT-6
Category RF/IF and RFID / RF Power Dividers/Splitters
Description
SPLITTER/COMBINER 2.1-2.3GHZ
PDF
/
Buying Options
Total Price: USD $29.06
Unit Price: USD $29.0567
≥1 USD $29.0567
≥10 USD $23.84215
≥100 USD $23.0964
≥500 USD $22.3516
≥1000 USD $21.6068
Inventory: 2508
Minimum: 1
-
+
Technical Details
Technical
VSWR-Max 1.3
Insertion Loss (dB) 0.55 dB
Characteristic Impedance 50Ohm
RF/Microwave Device Type SPLITTER AND COMBINER
Specifications Isolation (Min) 15dB, 3% Imbalance (Max)
Frequency 2.1GHz~2.3GHz
Construction COMPONENT
Additional Feature ISOLATION-MIN (DB):15
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 0.122Lx0.126W x 0.057 H 3.10mmx3.20mmx1.45mm
Published 2006
Packaging Tape & Reel (TR)
Dimensions
Height 1.1684mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Physical
Number of Pins 6
Package / Case SOT-6
