RoHS
RoHS RoHS compliant
Package 10-SMD, No Lead
Category RF/IF and RFID / RF Multiplexers
Description RF DIPLEXER 23.5MHZ/527MHZ 10SMD
PDF
/
Inventory: 9673
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Width 15.49mm
Length 29.97mm
Height 8.13mm

Technical

Receive Center Frequency 23.5MHz
Transmit Center Frequency 528MHz
Return Loss (Low Band / High Band) 12.0dB / 12.0dB
Frequency Bands (Low / High) 5MHz~42MHz / 54MHz~1GHz
Physical Dimension L29.97XB15.49XH8.13 (mm)/L1.18XB0.61XH0.32 (inch)
Type Diplexer
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2009
Packaging Tube

Physical

Package / Case 10-SMD, No Lead
Mounting Type Surface Mount
