LFD21859MDP1A049
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric), 8 PC Pad
Category RF/IF and RFID / RF Multiplexers
Description
Signal Conditioning CHIP MULTILAYER LC F
PDF
/
Buying Options
Total Price: USD $3.87
Unit Price: USD $3.8684
≥1 USD $3.8684
≥10 USD $3.17395
≥100 USD $3.07515
≥500 USD $2.9754
≥1000 USD $2.8766
Inventory: 20690
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 0805 (2012 Metric), 8 PC Pad
Number of Pins 8
Technical
Packaging Cut Tape (CT)
JESD-609 Code e3
Pbfree Code yes
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Diplexer
Terminal Finish Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Frequency 859.5MHz
Physical Dimension L2.0XB1.25XH0.9 (mm)/L0.079XB0.049XH0.035 (inch)
Frequency Bands (Low / High) 824MHz~894MHz / 1.85GHz~1.99GHz
High Band Attenuation (min / max dB) 20.00dB / -
Low Band Attenuation (min / max dB) 19.00dB / -
Insertion Loss (Tx) 0.45 dB
Insertion Loss (Rx) 0.4 dB
Dimensions
Height 0.9mm
Length 2mm
Width 1.25mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
