ACMD-7409-BLK
RoHS
/
Package 3-CSP
Category RF/IF and RFID / RF Multiplexers
Description
BROADCOM LIMITED ACMD-7409-BLK DUPLEXER, FBAR, PCS, MINI,
PDF
/
Buying Options
Total Price: USD $5.46
Unit Price: USD $5.4606
≥1 USD $5.4606
≥10 USD $4.48115
≥100 USD $4.34055
≥500 USD $4.2009
≥1000 USD $4.06125
Inventory: 2224
Minimum: 1
-
+
Technical Details
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 3-CSP
Number of Pins 3
Technical
Packaging Bulk
Published 2009
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
ECCN Code EAR99
Type Duplexer
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature ANTI-STATIC BAG
Reach Compliance Code unknown
Frequency 1.9895GHz
Insertion Loss (dB) 3.8 dB
Frequency Bands (Low / High) 1.85GHz~1.9GHz / 1.93GHz~1.99GHz
High Band Attenuation (min / max dB) 43.00dB / -
Low Band Attenuation (min / max dB) 52.00dB / -
Return Loss (Low Band / High Band) 20.0dB / 17.0dB
Dimensions
Height 1.2mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
