ACMD-6107-BLK

Broadcom Limited
RoHS
/
Package 8-VFQFN Exposed Pad, CSP
Category RF/IF and RFID / RF Multiplexers
Description RF Duplexer 2500MHz to 2570MHz 2620MHz to 2690MHz 9-Pin SMD Bag
PDF
/
Inventory: 2120
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Width 1.6mm
Length 2mm
Height 0.825mm

Technical

Receive Center Frequency 2655MHz
Transmit Center Frequency 2535MHz
Insertion Loss (Rx) 2.5 dB
Insertion Loss (Tx) 3 dB
Frequency Bands (Low / High) 2.5GHz~2.57GHz / 2.62GHz~2.69GHz
Operating Temperature (Min) -20°C
Operating Temperature (Max) 85°C
Additional Feature STRIP PACK; ANTISTATIC BAG
Type Duplexer
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Published 2012
Packaging Bulk

Physical

Number of Pins 9
Package / Case 8-VFQFN Exposed Pad, CSP
Mounting Type Surface Mount
Mount Surface Mount
