TRF370315IRGET
RoHS
RoHS compliant
RoHS compliantPackage 24-VFQFN Exposed Pad
Category RF/IF and RFID / RF Modulators
Description
IC QUADRATURE MODULATOR 24-QFN
PDF
/
Buying Options
Total Price: USD $13.23
Unit Price: USD $13.2264
≥1 USD $13.2264
≥10 USD $12.15896
≥100 USD $11.65472
≥500 USD $10.26872
Inventory: 124
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Package / Case 24-VFQFN Exposed Pad
Surface Mount YES
Number of Pins 24
Weight 45.387587mg
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 24
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8542.39.00.01
Subcategory Other Telecom ICs
Voltage - Supply 4.5V~5.5V
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.5mm
Frequency 4GHz
Base Part Number TRF370315
Function Modulator
Operating Supply Voltage 5.5V
Power Supplies 5V
Temperature Grade INDUSTRIAL
Test Frequency 2.14GHz
Operating Supply Current 235mA
Output Power -4.5dBm
Telecom IC Type RF AND BASEBAND CIRCUIT
P1dB 9.5dBm
RF Frequency 400MHz~4GHz
LO Frequency 400MHz~4GHz
Noise Floor -163dBm/Hz
Dimensions
Height 1mm
Length 4mm
Width 4mm
Thickness 880μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
