AD8349ARE
RoHS
/
Package 16-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category RF/IF and RFID / RF Modulators
Description
QUADRATURE MODULATOR
PDF
/
Buying Options
Total Price: USD $7.37
Unit Price: USD $7.3744
≥1 USD $7.3744
Inventory: 5604
Minimum: 1
-
+
Technical Details
Physical
Package / Case 16-TSSOP (0.173, 4.40mm Width) Exposed Pad
Technical
Packaging Tube
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Terminal Finish TIN LEAD
Voltage - Supply 4.75V~5.5V
Construction COMPONENT
Function Modulator
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Test Frequency 2.14GHz
Output Power 5.1dBm
Current - Supply 150mA
Operating Frequency-Max 2700MHz
Operating Frequency-Min 700MHz
Characteristic Impedance 50Ohm
P1dB 5.6dBm
RF Frequency 700MHz~2.7GHz
LO Frequency 700MHz~2.7GHz
Modulation Technique QPSK
Noise Floor -156dBm/Hz
Compliance
RoHS Status Non-RoHS Compliant
