STQ-3016

RFMD
RoHS
/
Package 16-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category RF/IF and RFID / RF Modulators
Description RF MODULATOR 2.5GHZ-4GHZ 16TSSOP
PDF
/
Inventory: 3572
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant

Technical

Noise Floor -153dBm/Hz
Modulation Technique QUADRAPHASE
LO Frequency 2.5GHz~4GHz
RF Frequency 2.5GHz~4GHz
P1dB 2dBm
Characteristic Impedance 50Ohm
Input Power-Max (CW) 10dBm
Operating Frequency-Min 2500MHz
Operating Frequency-Max 4000MHz
Output Power -12dBm
Operating Supply Current 88mA
Test Frequency 3GHz
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Function Modulator
Construction COMPONENT
Voltage - Supply 4.75V~5.25V
Terminal Finish Tin/Lead (Sn/Pb)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Published 2010
Packaging Tape & Reel (TR)

Physical

Package / Case 16-TSSOP (0.173, 4.40mm Width) Exposed Pad
