STQ-2016-3
RoHS
/
Package 16-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category RF/IF and RFID / RF Modulators
Description
RF MODULTR 700MHZ-2.5GHZ 16TSSOP
PDF
/
Inventory: 9579
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 4.3mm
Length 4.9mm
Height Seated (Max) 1.1mm
Technical
Noise Floor -156dBm/Hz
LO Frequency 700MHz~2.5GHz
RF Frequency 700MHz~2.5GHz
P1dB 3dBm
Telecom IC Type RF AND BASEBAND CIRCUIT
Output Power -11.5dBm
Operating Supply Current 86mA
Test Frequency 1.7GHz
Temperature Grade INDUSTRIAL
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
Function Modulator
JESD-30 Code R-PDSO-G16
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Terminal Pitch 0.6mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 235
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
HTS Code 8542.39.00.01
Terminal Finish TIN LEAD
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Published 2005
Packaging Tape & Reel (TR)
Physical
Surface Mount YES
Package / Case 16-TSSOP (0.173, 4.40mm Width) Exposed Pad
