LTC5599IUF#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 24-WFQFN Exposed Pad
Category RF/IF and RFID / RF Modulators
Description
RF MODULATOR 30MHZ-1.3GHZ 24QFN
PDF
/
Buying Options
Total Price: USD $25.61
Unit Price: USD $25.61105
≥1 USD $25.61105
≥10 USD $21.014
≥100 USD $20.35755
≥500 USD $19.70015
≥1000 USD $19.0437
Inventory: 1375
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 4mm
Length 4mm
Height Seated (Max) 0.8mm
Technical
Noise Floor -156.6dBm/Hz
LO Frequency 180MHz~1.9GHz
RF Frequency 30MHz~1.3GHz
P1dB 5dBm
Telecom IC Type RF AND BASEBAND CIRCUIT
Current - Supply 28mA
Test Frequency 500MHz
Function Modulator
JESD-30 Code S-PQCC-N24
Base Part Number LTC5599
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 2.7V~3.6V
Terminal Finish Matte Tin (Sn)
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2012
Packaging Tape & Reel (TR)
Physical
Surface Mount YES
Package / Case 24-WFQFN Exposed Pad
Supply Chain
Factory Lead Time 20 Weeks
