LTC5598IUF
RoHS
/
Package 24-WFQFN Exposed Pad
Category RF/IF and RFID / RF Modulators
Description
RF MODULATOR 5MHZ-1.6GHZ 24WFQFN
PDF
/
Buying Options
Total Price: USD $6.27
Unit Price: USD $6.2656
≥1 USD $6.2656
Inventory: 4576
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 4mm
Length 4mm
Height Seated (Max) 0.8mm
Technical
Noise Floor -160.3dBm/Hz
LO Frequency 5MHz~1.6GHz
RF Frequency 5MHz~1.6GHz
P1dB 8dBm
Telecom IC Type RF AND BASEBAND CIRCUIT
Current - Supply 165mA
Output Power 2dBm
Test Frequency 899.9MHz
Temperature Grade INDUSTRIAL
Power Supplies 5V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
Function Modulator
JESD-30 Code S-PQCC-N24
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.5mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 4.5V~5.25V
Technology CMOS
Subcategory Other Telecom ICs
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2010
Physical
Surface Mount YES
Package / Case 24-WFQFN Exposed Pad
Supply Chain
Factory Lead Time 14 Weeks
Alternative Model
