LT5571EUF#PBF
RoHS
RoHS compliant
RoHS compliantPackage 16-WQFN Exposed Pad
Category RF/IF and RFID / RF Modulators
Description
RF MODULATOR 620MHZ-1.1GHZ 16QFN
PDF
/
Buying Options
Total Price: USD $8.04
Unit Price: USD $8.038887
≥1 USD $8.038887
≥200 USD $3.111573
≥500 USD $3.002602
≥1000 USD $2.947461
Inventory: 939
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status PRODUCTION (Last Updated: 4 months ago)
Physical
Package / Case 16-WQFN Exposed Pad
Surface Mount YES
Number of Pins 16
Technical
Packaging Tube
Published 2006
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
HTS Code 8542.39.00.01
Subcategory Other Telecom ICs
Voltage - Supply 4.5V~5.25V
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number LT5571
Function Modulator
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Power Supplies 5V
Temperature Grade INDUSTRIAL
Test Frequency 900MHz
Operating Supply Current 120mA
Nominal Supply Current 97mA
Output Power -0.2dBm
Telecom IC Type RF AND BASEBAND CIRCUIT
P1dB 8.1dBm
RF Frequency 620MHz~1.1GHz
LO Frequency 500MHz~1.2GHz
Noise Floor -159dBm/Hz
Dimensions
Height Seated (Max) 0.8mm
Length 4mm
Width 4mm
Thickness 750μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
