LT5528EUF#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 16-WFQFN Exposed Pad
Category RF/IF and RFID / RF Modulators
Description
RF MODULATOR 1.5GHZ-2.4GHZ 16QFN
PDF
/
Buying Options
Total Price: USD $4.91
Unit Price: USD $4.90865
≥1 USD $4.90865
≥10 USD $4.028
≥100 USD $3.90165
≥500 USD $3.77625
≥1000 USD $3.6499
Inventory: 5136
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Noise Floor -159.3dBm/Hz
Modulation Technique QUADRAPHASE
LO Frequency 1.3GHz~2.7GHz
RF Frequency 1.5GHz~2.4GHz
P1dB 7.9dBm
Characteristic Impedance 50Ohm
Operating Frequency-Min 1500MHz
Operating Frequency-Max 2400MHz
Current - Supply 145mA
Output Power -2.1dBm
Test Frequency 2GHz
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Function Modulator
Base Part Number LT5528
Construction COMPONENT
Voltage - Supply 4.5V~5.25V
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2004
Packaging Tape & Reel (TR)
Physical
Package / Case 16-WFQFN Exposed Pad
Supply Chain
Factory Lead Time 26 Weeks
