LT5528EUF#PBF
RoHS
RoHS compliant
RoHS compliantPackage 16-WFQFN Exposed Pad
Category RF/IF and RFID / RF Modulators
Description
RF MODULATOR 1.5GHZ-2.4GHZ 16QFN
PDF
/
Buying Options
Total Price: USD $7.91
Unit Price: USD $7.9112
≥1 USD $7.9112
Inventory: 879
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Noise Floor -159dBm/Hz
Modulation Technique QUADRAPHASE
LO Frequency 1.5GHz~2.4GHz
RF Frequency 1.5GHz~2.4GHz
P1dB 7.9dBm
Characteristic Impedance 50Ohm
Operating Frequency-Min 1500MHz
Operating Frequency-Max 2400MHz
Output Power 4dBm
Operating Supply Current 125mA
Test Frequency 1.5GHz~2.4GHz
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Function Modulator
Base Part Number LT5528
Construction COMPONENT
Voltage - Supply 4.5V~5.25V
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2004
Packaging Tube
Physical
Number of Pins 16
Package / Case 16-WFQFN Exposed Pad
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 weeks ago)
Factory Lead Time 26 Weeks
