HMC697LP4 image
Favorite
HMC697LP4 image
Favorite
RoHS
/
Package 24-VFQFN Exposed Pad
Category RF/IF and RFID / RF Modulators
Description Quadrature Mod 4000MHz 24-Pin QFN Bulk
PDF
/
Inventory: 5585
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Lifecycle Status LAST TIME BUY (Last Updated: 3 days ago)

Physical

Package / Case 24-VFQFN Exposed Pad
Number of Pins 24
Weight 928.191737mg

Technical

Packaging Strip
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8542.39.00.01
Voltage - Supply 4.5V~5.5V
Construction COMPONENT
Reach Compliance Code not_compliant
Base Part Number HMC697
Function Modulator
Operating Supply Voltage 5V
Operating Supply Current 168mA
Output Power 3dBm
Max Frequency 4GHz
Operating Frequency-Max 4000MHz
Operating Frequency-Min 200MHz
Input Power-Max (CW) 18dBm
Characteristic Impedance 50Ohm
P1dB 8dBm
RF Frequency 200MHz~4GHz
LO Frequency 200MHz~4GHz
Modulation Technique QUADRAPHASE
Noise Floor -165dBm/Hz

Compliance

RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
