HMC497LP4
RoHS
/
Package 24-VFQFN Exposed Pad
Category RF/IF and RFID / RF Modulators
Description
Modulator / Demodulator SiGe Direct Modulator100 - 4000 MHz
PDF
/
Buying Options
Total Price: USD $3.04
Unit Price: USD $3.0419
≥1 USD $3.0419
≥10 USD $2.49565
≥100 USD $2.41775
≥500 USD $2.33985
≥1000 USD $2.26195
Inventory: 1165
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 4mm
Length 4mm
Height Seated (Max) 1mm
Technical
Noise Floor -159dBm/Hz
LO Frequency 100MHz~4GHz
RF Frequency 100MHz~4GHz
P1dB 8dBm
Telecom IC Type RF AND BASEBAND CIRCUIT
Max Frequency 4GHz
Output Power 5dBm
Operating Supply Current 168mA
Test Frequency 1.7GHz~2.2GHz
Temperature Grade INDUSTRIAL
Power Supplies 5V
Operating Supply Voltage 5V
Qualification Status Not Qualified
Function Modulator
Base Part Number HMC497
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code not_compliant
Terminal Pitch 0.5mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 235
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 4.5V~5.5V
Max Power Dissipation 1.8W
Subcategory Other Telecom ICs
HTS Code 8542.39.00.01
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Strip
Physical
Weight 928.191737mg
Number of Pins 24
Surface Mount YES
Package / Case 24-VFQFN Exposed Pad
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 5 days ago)
