HMC496LP3E
RoHS
RoHS compliant
RoHS compliantPackage 16-VFQFN Exposed Pad
Category RF/IF and RFID / RF Modulators
Description
RF MODULATOR 4GHZ-7GHZ 16VFQFN
PDF
/
Buying Options
Total Price: USD $259.53
Unit Price: USD $259.52955
≥1 USD $259.52955
≥10 USD $232.6816
Inventory: 261
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 1mm
Technical
Noise Floor -157dBM/Hz
LO Frequency 4GHz~7GHz
RF Frequency 4GHz~7GHz
P1dB 3dBm
Telecom IC Type TELECOM CIRCUIT
Output Power 2dBm
Operating Supply Current 93mA
Temperature Grade INDUSTRIAL
Operating Supply Voltage 3V
Qualification Status Not Qualified
Function Modulator
Base Part Number HMC496
Time@Peak Reflow Temperature-Max (s) 30
Frequency 6.4GHz
Terminal Pitch 0.5mm
Supply Voltage 3V
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 2.7V~3.3V
Max Power Dissipation 7W
HTS Code 8542.39.00.01
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e3
Packaging Strip
Physical
Weight 57.09594mg
Number of Pins 16
Surface Mount YES
Package / Case 16-VFQFN Exposed Pad
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 4 days ago)
