HMC1097LP4E
RoHS
RoHS compliant
RoHS compliantPackage 24-VFQFN Exposed Pad
Category RF/IF and RFID / RF Modulators
Description
Quadrature Mod 6000MHz 24-Pin QFN Bulk
PDF
/
Buying Options
Total Price: USD $96.03
Unit Price: USD $96.03265
≥1 USD $96.03265
≥10 USD $92.93565
≥100 USD $89.8377
≥500 USD $80.54385
Inventory: 1331
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status PRODUCTION (Last Updated: 3 weeks ago)
Physical
Contact Plating Tin
Mount Surface Mount
Package / Case 24-VFQFN Exposed Pad
Number of Pins 24
Weight 928.191737mg
Technical
Packaging Strip
JESD-609 Code e3
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8542.39.00.01
Max Power Dissipation 2.05W
Voltage - Supply 4.75V~5.25V
Base Part Number HMC1097
Function Modulator
Operating Supply Voltage 5V
Test Frequency 1.7GHz~2.2GHz
Operating Supply Current 170mA
Max Supply Current 170mA
Output Power 2.75dBm
Max Frequency 6GHz
P1dB 11dBm
RF Frequency 100MHz~6GHz
LO Frequency 100MHz~6GHz
Noise Floor -160dBm/Hz
Compliance
RoHS Status ROHS3 Compliant
