ADRF6720ACPZ-R7
RoHS
RoHS compliant
RoHS compliantPackage 40-WFQFN Exposed Pad
Category RF/IF and RFID / RF Modulators
Description
WIDEBAND INTEG MOD WITH PLL AND
PDF
/
Buying Options
Total Price: USD $96.03
Unit Price: USD $96.0336
≥1 USD $96.0336
≥10 USD $92.93565
≥100 USD $89.8377
≥500 USD $80.5448
Inventory: 1106
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 weeks ago)
Physical
Package / Case 40-WFQFN Exposed Pad
Surface Mount YES
Number of Pins 40
Technical
Packaging Cut Tape (CT)
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 40
ECCN Code 5A991.B
HTS Code 8542.39.00.01
Technology BICMOS
Voltage - Supply 3.3V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number ADRF6720
Function Modulator
Operating Temperature (Max) 85°C
Temperature Grade INDUSTRIAL
Test Frequency 2GHz
Analog IC - Other Type PHASE LOCKED LOOP
Operating Supply Current 420mA
Output Power 5dBm
P1dB 12.2dBm
LO Frequency 356MHz~2.855GHz
Noise Floor -158dBm/Hz
Dimensions
Height Seated (Max) 0.8mm
Length 6mm
Width 6mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
