AD8349AREZ
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category RF/IF and RFID / RF Modulators
Description
ANALOG DEVICES AD8349AREZ IC, QUADRATURE MODULATOR, SMD, 8349
PDF
/
Buying Options
Total Price: USD $13.32
Unit Price: USD $13.3232
≥1 USD $13.3232
≥10 USD $12.24784
≥100 USD $10.34403
≥500 USD $9.83635
≥1000 USD $9.201746
Inventory: 72
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Physical
Contact Plating Tin
Mount Surface Mount
Package / Case 16-TSSOP (0.173, 4.40mm Width) Exposed Pad
Number of Pins 16
Technical
Packaging Tube
JESD-609 Code e3
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Termination SMD/SMT
ECCN Code 5A991.B
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8542.39.00.01
Max Power Dissipation 800mW
Voltage - Supply 4.75V~5.5V
Construction COMPONENT
Frequency 2.7GHz
Base Part Number AD8349
Function Modulator
Test Frequency 2.14GHz
Operating Supply Current 135mA
Nominal Supply Current 135mA
Max Supply Current 150mA
Output Power 5.1dBm
Bandwidth 170MHz
Max Supply Voltage (DC) 5.25V
Characteristic Impedance 50Ohm
Min Supply Voltage (DC) 4.75V
P1dB 5.6dBm
RF Frequency 700MHz~2.7GHz
LO Frequency 700MHz~2.7GHz
Modulation Technique QPSK
Noise Floor -156dBm/Hz
Dimensions
Height 1mm
Length 5mm
Width 4.4mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
Alternative Model
