AD8346ARUZ
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width)
Category RF/IF and RFID / RF Modulators
Description
ANALOG DEVICES AD8346ARUZ. QUAD MODULATOR, 0.8-2.5GHZ, 16-TSSOP
PDF
/
Buying Options
Total Price: USD $12.39
Unit Price: USD $12.3904
≥1 USD $12.3904
≥10 USD $11.38984
≥100 USD $9.619685
≥500 USD $9.147538
≥1000 USD $8.557375
≥3000 USD $7.849169
Inventory: 191
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Physical
Contact Plating Tin
Mount Surface Mount
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Number of Pins 16
Technical
Packaging Tube
JESD-609 Code e3
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code 5A991.B
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8542.39.00.01
Max Power Dissipation 500mW
Voltage - Supply 2.7V~5.5V
Construction COMPONENT
Frequency 2.5GHz
Base Part Number AD8346
Function Modulator
Test Frequency 1.9GHz
Operating Supply Current 45mA
Nominal Supply Current 45mA
Max Supply Current 55mA
Output Power -6dBm
VSWR-Max 1.25
Input Power-Max (CW) 10dBm
Characteristic Impedance 50Ohm
P1dB -3dBm
RF Frequency 800MHz~2.5GHz
LO Frequency 800MHz~2.5GHz
Modulation Technique I/Q
Noise Floor -147dBm/Hz
Dimensions
Height 1.05mm
Length 5mm
Width 4.4mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
Alternative Model
