AD8345AREZ
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category RF/IF and RFID / RF Modulators
Description
ANALOG DEVICES AD8345AREZ. IC, QUAD MODULATOR, 140MHZ-1GHZ, 16-TSSO
PDF
/
Buying Options
Total Price: USD $12.08
Unit Price: USD $12.0821
≥1 USD $12.0821
≥10 USD $9.91325
≥100 USD $9.60355
≥500 USD $9.29385
≥1000 USD $8.98415
≥3000 USD $8.05505
Inventory: 652
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.4mm
Length 5mm
Height 1mm
Technical
Noise Floor -155dBm/Hz
Modulation Technique QUADRAPHASE
LO Frequency 140MHz~1GHz
RF Frequency 140MHz~1GHz
P1dB 2.5dBm
Characteristic Impedance 50Ohm
Input Power-Max (CW) 10dBm
Output Power 2dBm
Max Supply Current 78A
Nominal Supply Current 65mA
Operating Supply Current 65mA
Test Frequency 800MHz
Function Modulator
Base Part Number AD8345
Frequency 1GHz
Construction COMPONENT
Voltage - Supply 2.7V~5.5V
Max Power Dissipation 500mW
HTS Code 8542.39.00.01
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code 5A991.B
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code no
JESD-609 Code e3
Packaging Tube
Physical
Number of Pins 16
Package / Case 16-TSSOP (0.173, 4.40mm Width) Exposed Pad
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 8 Weeks
Alternative Model
