STW82103BTR
RoHS
RoHS compliant
RoHS compliantPackage 44-VFQFN Exposed Pad
Category RF/IF and RFID / RF Mixers
Description
IC MIXER 2.3-2.7GHZ DWN CONV
PDF
/
Inventory: 6558
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Lifecycle Status NRND (Last Updated: 7 months ago)
Physical
Mounting Type Surface Mount
Package / Case 44-VFQFN Exposed Pad
Surface Mount YES
Number of Pins 44
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 44
ECCN Code EAR99
Terminal Finish MATTE TIN
Technology BICMOS
Voltage - Supply 3V~5V
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Frequency 2.3GHz~2.7GHz
Base Part Number STW82103
Pin Count 44
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Supply Voltage-Max (Vsup) 3.45V
Temperature Grade INDUSTRIAL
Analog IC - Other Type PLL FREQUENCY SYNTHESIZER
Operating Supply Current 160mA
Gain 8.5dB
RF Type General Purpose
Secondary Attributes Down Converter
Noise Figure 10.5dB
Number of Mixers 1
Dimensions
Length 7mm
Width 7mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
