MAX9996ETP+
RoHS
RoHS compliant
RoHS compliantPackage 20-WQFN Exposed Pad
Category RF/IF and RFID / RF Mixers
Description
IC MIXER 1.7-2.2GHZ DWN 20TQFN
PDF
/
Buying Options
Total Price: USD $11.33
Unit Price: USD $11.3256
≥1 USD $11.3256
≥10 USD $10.41216
≥100 USD $9.98081
≥500 USD $8.79384
≥1000 USD $8.362288
≥3000 USD $7.822778
Inventory: 97
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
LO Tunable YES
Number of Mixers 1
Noise Figure 9.7dB
Secondary Attributes Down Converter
Characteristic Impedance 50Ohm
RF Type Cellular, DCS, EDGE, PCS, UMTS, WLL
Gain 8.3dB
Current - Supply 240mA
Power Supplies 5V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Frequency 1.7GHz~2.2GHz
Construction COMPONENT
Voltage - Supply 4.75V~5.25V
Technology BICMOS
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series MAX9996
Published 2005
Packaging Tube
Physical
Surface Mount YES
Package / Case 20-WQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
