MAX2044ETP+
RoHS
RoHS compliant
RoHS compliantPackage 20-WQFN Exposed Pad
Category RF/IF and RFID / RF Mixers
Description
RF Mixer 2.3GHz-4GHz Up/Down Mixer
PDF
/
Buying Options
Total Price: USD $2.36
Unit Price: USD $2.36075
≥1 USD $2.36075
≥10 USD $1.93705
≥100 USD $1.87625
≥500 USD $1.81545
≥1000 USD $1.7556
Inventory: 7003
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 5mm
Length 5mm
Height Seated (Max) 0.8mm
Technical
Number of Mixers 1
Noise Figure 8.5dB
Secondary Attributes Up/Down Converter
RF Type WiMax, WLAN
Telecom IC Type RF AND BASEBAND CIRCUIT
Operating Supply Current 138mA
Temperature Grade INDUSTRIAL
Operating Supply Voltage 5V
Pin Count 20
Base Part Number MAX2044
Frequency 2.3GHz~4GHz
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Voltage - Supply 3.3V 5V
Technology BICMOS
Max Power Dissipation 5W
Subcategory Other Telecom ICs
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2010
Packaging Tube
Physical
Number of Pins 20
Surface Mount YES
Package / Case 20-WQFN Exposed Pad
Mounting Type Surface Mount
