LTC5592IUH#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 24-WQFN Exposed Pad
Category RF/IF and RFID / RF Mixers
Description
IC MIXR 1.6-2.7GHZ DWNCONV 24QFN
PDF
/
Buying Options
Total Price: USD $153.92
Unit Price: USD $153.9209
≥1 USD $153.9209
≥10 USD $148.7909
≥100 USD $133.39805
Inventory: 1105
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5mm
Length 5mm
Height Seated (Max) 0.8mm
Technical
Number of Mixers 2
Noise Figure 9.9dB
Secondary Attributes Down Converter
RF Type GSM, LTE, W-CDMA
Telecom IC Type RF AND BASEBAND CIRCUIT
Gain 8.1dB
Current - Supply 401mA
Temperature Grade INDUSTRIAL
Operating Temperature (Min) -40°C
Operating Temperature (Max) 105°C
Qualification Status Not Qualified
Pin Count 24
Base Part Number LTC5592
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 1.6GHz~2.7GHz
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 3.1V~5.3V
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2011
Packaging Tape & Reel (TR)
Physical
Surface Mount YES
Package / Case 24-WQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
